nw.jsでデスクトップアプリを作る(15) - SVG pathをgeometryに変換する(5)

公開:2015-02-27 21:19
更新:2017-09-22 05:40
カテゴリ:nw.js,svg,three.js,javascript,webgl,html5,nw.jsでデスクトップアプリを作る

pathの絶対座標を相対座標に変換する問題はググるとあっけなく解決した。

javascript - Convert SVG Path to Relative Commands - Stack Overflow

上記記事中のconvertToRelative()によって変換することができた。下記はSVGで適当にアニメーションしてみたもの。

動作サンプル

新しいウィンドウで開く

ソースコード・リソース

/dev/horse/0001/index.html

<!DOCTYPE html>
<html vocab="http://schema.org" lang="ja">
<head>
  <title>SVGアニメーションのテスト</title>
  <meta charset="utf-8" />
  <meta name="description" content="SVGアニメーションのテスト" />
  <meta name="keywords" content="Youtube,d3.js,Q.js,jquery" />
  <meta name="author" content="sfpgmr" />
  <meta name="viewport" content="width=device-width, initial-scale=1, maximum-scale=1, user-scalable=no" />
  <script type="text/javascript" src="./pathseg.js"></script>
  <script type="text/javascript" src="//cdnjs.cloudflare.com/ajax/libs/d3/3.5.2/d3.js"></script>
  <script type="text/javascript" src="//cdnjs.cloudflare.com/ajax/libs/three.js/r70/three.js"></script>
  <script type="text/javascript" src="//cdnjs.cloudflare.com/ajax/libs/q.js/1.1.2/q.min.js" ></script>
  <!--<script type="text/javascript" src="./graphics.js"></script> -->
  <link rel="stylesheet" href="//cdnjs.cloudflare.com/ajax/libs/normalize/3.0.2/normalize.min.css" />
  <style>
    body {
      margin: 0;
      padding: 0;
      overflow: hidden;
    }
    #svg {
/*
  display:none;
*/
    }
  </style>

</head>
<body>
  <div id="content"></div>
  <div id="svg"></div>
  <script type="text/javascript" src="index.js"></script>
  <script>
  </script>
</body>
</html>

/dev/horse/0001/index.js

/// <reference path="http://cdnjs.cloudflare.com/ajax/libs/d3/3.5.2/d3.js" />
/// <reference path="http://cdnjs.cloudflare.com/ajax/libs/three.js/r70/three.js" />
/// <reference path="..\intellisense\q.intellisense.js" />

"use strict"

// stackoverflow‚æ‚è”qŽØ
// http://stackoverflow.com/questions/14179333/convert-svg-path-to-relative-commands
function convertToRelative(path) {
  function set(type) {
    var args = [].slice.call(arguments, 1)
      , rcmd = 'createSVGPathSeg'+ type +'Rel'
      , rseg = path[rcmd].apply(path, args);
    segs.replaceItem(rseg, i);
  }
  var dx, dy, x0, y0, x1, y1, x2, y2, segs = path.pathSegList;
  for (var x = 0, y = 0, i = 0, len = segs.numberOfItems; i < len; i++) {
    var seg = segs.getItem(i)
      , c   = seg.pathSegTypeAsLetter;
    if (/[MLHVCSQTAZz]/.test(c)) {
      if ('x1' in seg) x1 = seg.x1 - x;
      if ('x2' in seg) x2 = seg.x2 - x;
      if ('y1' in seg) y1 = seg.y1 - y;
      if ('y2' in seg) y2 = seg.y2 - y;
      if ('x'  in seg) dx = -x + (x = seg.x);
      if ('y'  in seg) dy = -y + (y = seg.y);
      switch (c) {
        case 'M': set('Moveto',dx,dy);                   break;
        case 'L': set('Lineto',dx,dy);                   break;
        case 'H': set('LinetoHorizontal',dx);            break;
        case 'V': set('LinetoVertical',dy);              break;
        case 'C': set('CurvetoCubic',dx,dy,x1,y1,x2,y2); break;
        case 'S': set('CurvetoCubicSmooth',dx,dy,x2,y2); break;
        case 'Q': set('CurvetoQuadratic',dx,dy,x1,y1);   break;
        case 'T': set('CurvetoQuadraticSmooth',dx,dy);   break;
        case 'A': set('Arc',dx,dy,seg.r1,seg.r2,seg.angle,
                      seg.largeArcFlag,seg.sweepFlag);   break;
        case 'Z': case 'z': x = x0; y = y0; break;
      }
    }
    else {
      if ('x' in seg) x += seg.x;
      if ('y' in seg) y += seg.y;
    }
    // store the start of a subpath
    if (c == 'M' || c == 'm') {
      x0 = x;
      y0 = y;
    }
  }
  path.setAttribute('d', path.getAttribute('d').replace(/Z/g, 'z'));
}
window.addEventListener('load',function(){
  var xml = Q.nfbind(d3.xml);
  xml('./horse00.svg','image/svg+xml')
  .then(function(svg){
    try {
      document.querySelector('#svg').appendChild(svg.firstChild);

      var gs = d3.select('svg').selectAll('g')[0];
      gs.forEach(function(g){
        var boundingBox = g.querySelector('rect');
        var path = g.querySelector('path');
        convertToRelative(path);
        // ***** 2/28修正 **** //
        var m = path.createSVGPathSegMovetoRel
          (path.pathSegList[0].x - boundingBox.x.baseVal.value - boundingBox.width.baseVal.value / 2.0,
          path.pathSegList[0].y - boundingBox.y.baseVal.value - boundingBox.height.baseVal.value / 2.0
          );
        path.pathSegList.replaceItem(m,0);
        // *** 直接代入できない **//
//        path.animatedPathSegList[0].x = path.animatedPathSegList[0].x - boundingBox.x.baseVal.value - boundingBox.width.baseVal.value / 2.0;
//        path.animatedPathSegList[0].y = path.animatedPathSegList[0].y - boundingBox.y.baseVal.value - boundingBox.height.baseVal.value / 2.0;

        path.setAttribute('d',path.getAttribute('d'));
        g.removeChild(boundingBox);
        g.setAttribute('transform','translate(' + window.innerWidth / 2 + ',' + window.innerHeight /2 + ')');
        window.addEventListener('resize',function(){
          g.setAttribute('transform','translate(' + window.innerWidth / 2 + ',' + window.innerHeight /2 + ')');
        });
        g.style.display = 'none';
      });
    } catch (e) {
      console.log(e);
    }

    //•`‰æ
    (function render(index){
      var gs = d3.select('svg').selectAll('g')[0];
      gs[index].style.display = "inline";
      if(index == 0){
        gs[10].style.display = 'none';
      } else {
        gs[index - 1].style.display = 'none';
      }
      ++index;
      if(index > 10) index = 0;
      window.setTimeout(render.bind(null,index),38);
    })(0);
//    console.log(d3.select('#svg').html());
  });
});

/dev/horse/0001/pathseg.js

// SVGPathSeg API polyfill
// https://github.com/progers/pathseg
//
// This is a drop-in replacement for the SVGPathSeg and SVGPathSegList APIs that were removed from
// SVG2 (https://lists.w3.org/Archives/Public/www-svg/2015Jun/0044.html), including the latest spec
// changes which were implemented in Firefox 43 and Chrome 46.

(function() { "use strict";
    if (!("SVGPathSeg" in window)) {
        // Spec: http://www.w3.org/TR/SVG11/single-page.html#paths-InterfaceSVGPathSeg
        window.SVGPathSeg = function(type, typeAsLetter, owningPathSegList) {
            this.pathSegType = type;
            this.pathSegTypeAsLetter = typeAsLetter;
            this._owningPathSegList = owningPathSegList;
        }

        window.SVGPathSeg.prototype.classname = "SVGPathSeg";

        window.SVGPathSeg.PATHSEG_UNKNOWN = 0;
        window.SVGPathSeg.PATHSEG_CLOSEPATH = 1;
        window.SVGPathSeg.PATHSEG_MOVETO_ABS = 2;
        window.SVGPathSeg.PATHSEG_MOVETO_REL = 3;
        window.SVGPathSeg.PATHSEG_LINETO_ABS = 4;
        window.SVGPathSeg.PATHSEG_LINETO_REL = 5;
        window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_ABS = 6;
        window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_REL = 7;
        window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_ABS = 8;
        window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_REL = 9;
        window.SVGPathSeg.PATHSEG_ARC_ABS = 10;
        window.SVGPathSeg.PATHSEG_ARC_REL = 11;
        window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_ABS = 12;
        window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_REL = 13;
        window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_ABS = 14;
        window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_REL = 15;
        window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_ABS = 16;
        window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_REL = 17;
        window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_ABS = 18;
        window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_REL = 19;

        // Notify owning PathSegList on any changes so they can be synchronized back to the path element.
        window.SVGPathSeg.prototype._segmentChanged = function() {
            if (this._owningPathSegList)
                this._owningPathSegList.segmentChanged(this);
        }

        window.SVGPathSegClosePath = function(owningPathSegList) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CLOSEPATH, "z", owningPathSegList);
        }
        window.SVGPathSegClosePath.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegClosePath.prototype.toString = function() { return "[object SVGPathSegClosePath]"; }
        window.SVGPathSegClosePath.prototype._asPathString = function() { return this.pathSegTypeAsLetter; }
        window.SVGPathSegClosePath.prototype.clone = function() { return new window.SVGPathSegClosePath(undefined); }

        window.SVGPathSegMovetoAbs = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_MOVETO_ABS, "M", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegMovetoAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegMovetoAbs.prototype.toString = function() { return "[object SVGPathSegMovetoAbs]"; }
        window.SVGPathSegMovetoAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegMovetoAbs.prototype.clone = function() { return new window.SVGPathSegMovetoAbs(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegMovetoAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegMovetoAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegMovetoRel = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_MOVETO_REL, "m", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegMovetoRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegMovetoRel.prototype.toString = function() { return "[object SVGPathSegMovetoRel]"; }
        window.SVGPathSegMovetoRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegMovetoRel.prototype.clone = function() { return new window.SVGPathSegMovetoRel(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegMovetoRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegMovetoRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoAbs = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_ABS, "L", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegLinetoAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoAbs.prototype.toString = function() { return "[object SVGPathSegLinetoAbs]"; }
        window.SVGPathSegLinetoAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegLinetoAbs.prototype.clone = function() { return new window.SVGPathSegLinetoAbs(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegLinetoAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegLinetoAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoRel = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_REL, "l", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegLinetoRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoRel.prototype.toString = function() { return "[object SVGPathSegLinetoRel]"; }
        window.SVGPathSegLinetoRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegLinetoRel.prototype.clone = function() { return new window.SVGPathSegLinetoRel(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegLinetoRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegLinetoRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoCubicAbs = function(owningPathSegList, x, y, x1, y1, x2, y2) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_ABS, "C", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x1 = x1;
            this._y1 = y1;
            this._x2 = x2;
            this._y2 = y2;
        }
        window.SVGPathSegCurvetoCubicAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoCubicAbs.prototype.toString = function() { return "[object SVGPathSegCurvetoCubicAbs]"; }
        window.SVGPathSegCurvetoCubicAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x1 + " " + this._y1 + " " + this._x2 + " " + this._y2 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoCubicAbs.prototype.clone = function() { return new window.SVGPathSegCurvetoCubicAbs(undefined, this._x, this._y, this._x1, this._y1, this._x2, this._y2); }
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "x1", { get: function() { return this._x1; }, set: function(x1) { this._x1 = x1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "y1", { get: function() { return this._y1; }, set: function(y1) { this._y1 = y1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "x2", { get: function() { return this._x2; }, set: function(x2) { this._x2 = x2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicAbs.prototype, "y2", { get: function() { return this._y2; }, set: function(y2) { this._y2 = y2; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoCubicRel = function(owningPathSegList, x, y, x1, y1, x2, y2) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_REL, "c", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x1 = x1;
            this._y1 = y1;
            this._x2 = x2;
            this._y2 = y2;
        }
        window.SVGPathSegCurvetoCubicRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoCubicRel.prototype.toString = function() { return "[object SVGPathSegCurvetoCubicRel]"; }
        window.SVGPathSegCurvetoCubicRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x1 + " " + this._y1 + " " + this._x2 + " " + this._y2 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoCubicRel.prototype.clone = function() { return new window.SVGPathSegCurvetoCubicRel(undefined, this._x, this._y, this._x1, this._y1, this._x2, this._y2); }
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "x1", { get: function() { return this._x1; }, set: function(x1) { this._x1 = x1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "y1", { get: function() { return this._y1; }, set: function(y1) { this._y1 = y1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "x2", { get: function() { return this._x2; }, set: function(x2) { this._x2 = x2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicRel.prototype, "y2", { get: function() { return this._y2; }, set: function(y2) { this._y2 = y2; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoQuadraticAbs = function(owningPathSegList, x, y, x1, y1) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_ABS, "Q", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x1 = x1;
            this._y1 = y1;
        }
        window.SVGPathSegCurvetoQuadraticAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoQuadraticAbs.prototype.toString = function() { return "[object SVGPathSegCurvetoQuadraticAbs]"; }
        window.SVGPathSegCurvetoQuadraticAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x1 + " " + this._y1 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoQuadraticAbs.prototype.clone = function() { return new window.SVGPathSegCurvetoQuadraticAbs(undefined, this._x, this._y, this._x1, this._y1); }
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticAbs.prototype, "x1", { get: function() { return this._x1; }, set: function(x1) { this._x1 = x1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticAbs.prototype, "y1", { get: function() { return this._y1; }, set: function(y1) { this._y1 = y1; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoQuadraticRel = function(owningPathSegList, x, y, x1, y1) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_REL, "q", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x1 = x1;
            this._y1 = y1;
        }
        window.SVGPathSegCurvetoQuadraticRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoQuadraticRel.prototype.toString = function() { return "[object SVGPathSegCurvetoQuadraticRel]"; }
        window.SVGPathSegCurvetoQuadraticRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x1 + " " + this._y1 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoQuadraticRel.prototype.clone = function() { return new window.SVGPathSegCurvetoQuadraticRel(undefined, this._x, this._y, this._x1, this._y1); }
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticRel.prototype, "x1", { get: function() { return this._x1; }, set: function(x1) { this._x1 = x1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticRel.prototype, "y1", { get: function() { return this._y1; }, set: function(y1) { this._y1 = y1; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegArcAbs = function(owningPathSegList, x, y, r1, r2, angle, largeArcFlag, sweepFlag) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_ARC_ABS, "A", owningPathSegList);
            this._x = x;
            this._y = y;
            this._r1 = r1;
            this._r2 = r2;
            this._angle = angle;
            this._largeArcFlag = largeArcFlag;
            this._sweepFlag = sweepFlag;
        }
        window.SVGPathSegArcAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegArcAbs.prototype.toString = function() { return "[object SVGPathSegArcAbs]"; }
        window.SVGPathSegArcAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._r1 + " " + this._r2 + " " + this._angle + " " + (this._largeArcFlag ? "1" : "0") + " " + (this._sweepFlag ? "1" : "0") + " " + this._x + " " + this._y; }
        window.SVGPathSegArcAbs.prototype.clone = function() { return new window.SVGPathSegArcAbs(undefined, this._x, this._y, this._r1, this._r2, this._angle, this._largeArcFlag, this._sweepFlag); }
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "r1", { get: function() { return this._r1; }, set: function(r1) { this._r1 = r1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "r2", { get: function() { return this._r2; }, set: function(r2) { this._r2 = r2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "angle", { get: function() { return this._angle; }, set: function(angle) { this._angle = angle; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "largeArcFlag", { get: function() { return this._largeArcFlag; }, set: function(largeArcFlag) { this._largeArcFlag = largeArcFlag; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcAbs.prototype, "sweepFlag", { get: function() { return this._sweepFlag; }, set: function(sweepFlag) { this._sweepFlag = sweepFlag; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegArcRel = function(owningPathSegList, x, y, r1, r2, angle, largeArcFlag, sweepFlag) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_ARC_REL, "a", owningPathSegList);
            this._x = x;
            this._y = y;
            this._r1 = r1;
            this._r2 = r2;
            this._angle = angle;
            this._largeArcFlag = largeArcFlag;
            this._sweepFlag = sweepFlag;
        }
        window.SVGPathSegArcRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegArcRel.prototype.toString = function() { return "[object SVGPathSegArcRel]"; }
        window.SVGPathSegArcRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._r1 + " " + this._r2 + " " + this._angle + " " + (this._largeArcFlag ? "1" : "0") + " " + (this._sweepFlag ? "1" : "0") + " " + this._x + " " + this._y; }
        window.SVGPathSegArcRel.prototype.clone = function() { return new window.SVGPathSegArcRel(undefined, this._x, this._y, this._r1, this._r2, this._angle, this._largeArcFlag, this._sweepFlag); }
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "r1", { get: function() { return this._r1; }, set: function(r1) { this._r1 = r1; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "r2", { get: function() { return this._r2; }, set: function(r2) { this._r2 = r2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "angle", { get: function() { return this._angle; }, set: function(angle) { this._angle = angle; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "largeArcFlag", { get: function() { return this._largeArcFlag; }, set: function(largeArcFlag) { this._largeArcFlag = largeArcFlag; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegArcRel.prototype, "sweepFlag", { get: function() { return this._sweepFlag; }, set: function(sweepFlag) { this._sweepFlag = sweepFlag; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoHorizontalAbs = function(owningPathSegList, x) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_ABS, "H", owningPathSegList);
            this._x = x;
        }
        window.SVGPathSegLinetoHorizontalAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoHorizontalAbs.prototype.toString = function() { return "[object SVGPathSegLinetoHorizontalAbs]"; }
        window.SVGPathSegLinetoHorizontalAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x; }
        window.SVGPathSegLinetoHorizontalAbs.prototype.clone = function() { return new window.SVGPathSegLinetoHorizontalAbs(undefined, this._x); }
        Object.defineProperty(window.SVGPathSegLinetoHorizontalAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoHorizontalRel = function(owningPathSegList, x) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_REL, "h", owningPathSegList);
            this._x = x;
        }
        window.SVGPathSegLinetoHorizontalRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoHorizontalRel.prototype.toString = function() { return "[object SVGPathSegLinetoHorizontalRel]"; }
        window.SVGPathSegLinetoHorizontalRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x; }
        window.SVGPathSegLinetoHorizontalRel.prototype.clone = function() { return new window.SVGPathSegLinetoHorizontalRel(undefined, this._x); }
        Object.defineProperty(window.SVGPathSegLinetoHorizontalRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoVerticalAbs = function(owningPathSegList, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_ABS, "V", owningPathSegList);
            this._y = y;
        }
        window.SVGPathSegLinetoVerticalAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoVerticalAbs.prototype.toString = function() { return "[object SVGPathSegLinetoVerticalAbs]"; }
        window.SVGPathSegLinetoVerticalAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._y; }
        window.SVGPathSegLinetoVerticalAbs.prototype.clone = function() { return new window.SVGPathSegLinetoVerticalAbs(undefined, this._y); }
        Object.defineProperty(window.SVGPathSegLinetoVerticalAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegLinetoVerticalRel = function(owningPathSegList, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_REL, "v", owningPathSegList);
            this._y = y;
        }
        window.SVGPathSegLinetoVerticalRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegLinetoVerticalRel.prototype.toString = function() { return "[object SVGPathSegLinetoVerticalRel]"; }
        window.SVGPathSegLinetoVerticalRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._y; }
        window.SVGPathSegLinetoVerticalRel.prototype.clone = function() { return new window.SVGPathSegLinetoVerticalRel(undefined, this._y); }
        Object.defineProperty(window.SVGPathSegLinetoVerticalRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoCubicSmoothAbs = function(owningPathSegList, x, y, x2, y2) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_ABS, "S", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x2 = x2;
            this._y2 = y2;
        }
        window.SVGPathSegCurvetoCubicSmoothAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoCubicSmoothAbs.prototype.toString = function() { return "[object SVGPathSegCurvetoCubicSmoothAbs]"; }
        window.SVGPathSegCurvetoCubicSmoothAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x2 + " " + this._y2 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoCubicSmoothAbs.prototype.clone = function() { return new window.SVGPathSegCurvetoCubicSmoothAbs(undefined, this._x, this._y, this._x2, this._y2); }
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothAbs.prototype, "x2", { get: function() { return this._x2; }, set: function(x2) { this._x2 = x2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothAbs.prototype, "y2", { get: function() { return this._y2; }, set: function(y2) { this._y2 = y2; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoCubicSmoothRel = function(owningPathSegList, x, y, x2, y2) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_REL, "s", owningPathSegList);
            this._x = x;
            this._y = y;
            this._x2 = x2;
            this._y2 = y2;
        }
        window.SVGPathSegCurvetoCubicSmoothRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoCubicSmoothRel.prototype.toString = function() { return "[object SVGPathSegCurvetoCubicSmoothRel]"; }
        window.SVGPathSegCurvetoCubicSmoothRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x2 + " " + this._y2 + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoCubicSmoothRel.prototype.clone = function() { return new window.SVGPathSegCurvetoCubicSmoothRel(undefined, this._x, this._y, this._x2, this._y2); }
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothRel.prototype, "x2", { get: function() { return this._x2; }, set: function(x2) { this._x2 = x2; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoCubicSmoothRel.prototype, "y2", { get: function() { return this._y2; }, set: function(y2) { this._y2 = y2; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoQuadraticSmoothAbs = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_ABS, "T", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype.toString = function() { return "[object SVGPathSegCurvetoQuadraticSmoothAbs]"; }
        window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype.clone = function() { return new window.SVGPathSegCurvetoQuadraticSmoothAbs(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticSmoothAbs.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        window.SVGPathSegCurvetoQuadraticSmoothRel = function(owningPathSegList, x, y) {
            window.SVGPathSeg.call(this, window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_REL, "t", owningPathSegList);
            this._x = x;
            this._y = y;
        }
        window.SVGPathSegCurvetoQuadraticSmoothRel.prototype = Object.create(window.SVGPathSeg.prototype);
        window.SVGPathSegCurvetoQuadraticSmoothRel.prototype.toString = function() { return "[object SVGPathSegCurvetoQuadraticSmoothRel]"; }
        window.SVGPathSegCurvetoQuadraticSmoothRel.prototype._asPathString = function() { return this.pathSegTypeAsLetter + " " + this._x + " " + this._y; }
        window.SVGPathSegCurvetoQuadraticSmoothRel.prototype.clone = function() { return new window.SVGPathSegCurvetoQuadraticSmoothRel(undefined, this._x, this._y); }
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticSmoothRel.prototype, "x", { get: function() { return this._x; }, set: function(x) { this._x = x; this._segmentChanged(); }, enumerable: true });
        Object.defineProperty(window.SVGPathSegCurvetoQuadraticSmoothRel.prototype, "y", { get: function() { return this._y; }, set: function(y) { this._y = y; this._segmentChanged(); }, enumerable: true });

        // Add createSVGPathSeg* functions to window.SVGPathElement.
        // Spec: http://www.w3.org/TR/SVG11/single-page.html#paths-Interfacewindow.SVGPathElement.
        window.SVGPathElement.prototype.createSVGPathSegClosePath = function() { return new window.SVGPathSegClosePath(undefined); }
        window.SVGPathElement.prototype.createSVGPathSegMovetoAbs = function(x, y) { return new window.SVGPathSegMovetoAbs(undefined, x, y); }
        window.SVGPathElement.prototype.createSVGPathSegMovetoRel = function(x, y) { return new window.SVGPathSegMovetoRel(undefined, x, y); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoAbs = function(x, y) { return new window.SVGPathSegLinetoAbs(undefined, x, y); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoRel = function(x, y) { return new window.SVGPathSegLinetoRel(undefined, x, y); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoCubicAbs = function(x, y, x1, y1, x2, y2) { return new window.SVGPathSegCurvetoCubicAbs(undefined, x, y, x1, y1, x2, y2); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoCubicRel = function(x, y, x1, y1, x2, y2) { return new window.SVGPathSegCurvetoCubicRel(undefined, x, y, x1, y1, x2, y2); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoQuadraticAbs = function(x, y, x1, y1) { return new window.SVGPathSegCurvetoQuadraticAbs(undefined, x, y, x1, y1); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoQuadraticRel = function(x, y, x1, y1) { return new window.SVGPathSegCurvetoQuadraticRel(undefined, x, y, x1, y1); }
        window.SVGPathElement.prototype.createSVGPathSegArcAbs = function(x, y, r1, r2, angle, largeArcFlag, sweepFlag) { return new window.SVGPathSegArcAbs(undefined, x, y, r1, r2, angle, largeArcFlag, sweepFlag); }
        window.SVGPathElement.prototype.createSVGPathSegArcRel = function(x, y, r1, r2, angle, largeArcFlag, sweepFlag) { return new window.SVGPathSegArcRel(undefined, x, y, r1, r2, angle, largeArcFlag, sweepFlag); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoHorizontalAbs = function(x) { return new window.SVGPathSegLinetoHorizontalAbs(undefined, x); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoHorizontalRel = function(x) { return new window.SVGPathSegLinetoHorizontalRel(undefined, x); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoVerticalAbs = function(y) { return new window.SVGPathSegLinetoVerticalAbs(undefined, y); }
        window.SVGPathElement.prototype.createSVGPathSegLinetoVerticalRel = function(y) { return new window.SVGPathSegLinetoVerticalRel(undefined, y); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoCubicSmoothAbs = function(x, y, x2, y2) { return new window.SVGPathSegCurvetoCubicSmoothAbs(undefined, x, y, x2, y2); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoCubicSmoothRel = function(x, y, x2, y2) { return new window.SVGPathSegCurvetoCubicSmoothRel(undefined, x, y, x2, y2); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoQuadraticSmoothAbs = function(x, y) { return new window.SVGPathSegCurvetoQuadraticSmoothAbs(undefined, x, y); }
        window.SVGPathElement.prototype.createSVGPathSegCurvetoQuadraticSmoothRel = function(x, y) { return new window.SVGPathSegCurvetoQuadraticSmoothRel(undefined, x, y); }
    }

    if (!("SVGPathSegList" in window)) {
        // Spec: http://www.w3.org/TR/SVG11/single-page.html#paths-InterfaceSVGPathSegList
        window.SVGPathSegList = function(pathElement) {
            this._pathElement = pathElement;
            this._list = this._parsePath(this._pathElement.getAttribute("d"));

            // Use a MutationObserver to catch changes to the path's "d" attribute.
            this._mutationObserverConfig = { "attributes": true, "attributeFilter": ["d"] };
            this._pathElementMutationObserver = new MutationObserver(this._updateListFromPathMutations.bind(this));
            this._pathElementMutationObserver.observe(this._pathElement, this._mutationObserverConfig);
        }

        window.SVGPathSegList.prototype.classname = "SVGPathSegList";

        Object.defineProperty(window.SVGPathSegList.prototype, "numberOfItems", {
            get: function() {
                this._checkPathSynchronizedToList();
                return this._list.length;
            },
            enumerable: true
        });

        // Add the pathSegList accessors to window.SVGPathElement.
        // Spec: http://www.w3.org/TR/SVG11/single-page.html#paths-InterfaceSVGAnimatedPathData
        Object.defineProperty(window.SVGPathElement.prototype, "pathSegList", {
            get: function() {
                if (!this._pathSegList)
                    this._pathSegList = new window.SVGPathSegList(this);
                return this._pathSegList;
            },
            enumerable: true
        });
        // FIXME: The following are not implemented and simply return window.SVGPathElement.pathSegList.
        Object.defineProperty(window.SVGPathElement.prototype, "normalizedPathSegList", { get: function() { return this.pathSegList; }, enumerable: true });
        Object.defineProperty(window.SVGPathElement.prototype, "animatedPathSegList", { get: function() { return this.pathSegList; }, enumerable: true });
        Object.defineProperty(window.SVGPathElement.prototype, "animatedNormalizedPathSegList", { get: function() { return this.pathSegList; }, enumerable: true });

        // Process any pending mutations to the path element and update the list as needed.
        // This should be the first call of all public functions and is needed because
        // MutationObservers are not synchronous so we can have pending asynchronous mutations.
        window.SVGPathSegList.prototype._checkPathSynchronizedToList = function() {
            this._updateListFromPathMutations(this._pathElementMutationObserver.takeRecords());
        }

        window.SVGPathSegList.prototype._updateListFromPathMutations = function(mutationRecords) {
            if (!this._pathElement)
                return;
            var hasPathMutations = false;
            mutationRecords.forEach(function(record) {
                if (record.attributeName == "d")
                    hasPathMutations = true;
            });
            if (hasPathMutations)
                this._list = this._parsePath(this._pathElement.getAttribute("d"));
        }

        // Serialize the list and update the path's 'd' attribute.
        window.SVGPathSegList.prototype._writeListToPath = function() {
            this._pathElementMutationObserver.disconnect();
            this._pathElement.setAttribute("d", window.SVGPathSegList._pathSegArrayAsString(this._list));
            this._pathElementMutationObserver.observe(this._pathElement, this._mutationObserverConfig);
        }

        // When a path segment changes the list needs to be synchronized back to the path element.
        window.SVGPathSegList.prototype.segmentChanged = function(pathSeg) {
            this._writeListToPath();
        }

        window.SVGPathSegList.prototype.clear = function() {
            this._checkPathSynchronizedToList();

            this._list.forEach(function(pathSeg) {
                pathSeg._owningPathSegList = null;
            });
            this._list = [];
            this._writeListToPath();
        }

        window.SVGPathSegList.prototype.initialize = function(newItem) {
            this._checkPathSynchronizedToList();

            this._list = [newItem];
            newItem._owningPathSegList = this;
            this._writeListToPath();
            return newItem;
        }

        window.SVGPathSegList.prototype._checkValidIndex = function(index) {
            if (isNaN(index) || index < 0 || index >= this.numberOfItems)
                throw "INDEX_SIZE_ERR";
        }

        window.SVGPathSegList.prototype.getItem = function(index) {
            this._checkPathSynchronizedToList();

            this._checkValidIndex(index);
            return this._list[index];
        }

        window.SVGPathSegList.prototype.insertItemBefore = function(newItem, index) {
            this._checkPathSynchronizedToList();

            // Spec: If the index is greater than or equal to numberOfItems, then the new item is appended to the end of the list.
            if (index > this.numberOfItems)
                index = this.numberOfItems;
            if (newItem._owningPathSegList) {
                // SVG2 spec says to make a copy.
                newItem = newItem.clone();
            }
            this._list.splice(index, 0, newItem);
            newItem._owningPathSegList = this;
            this._writeListToPath();
            return newItem;
        }

        window.SVGPathSegList.prototype.replaceItem = function(newItem, index) {
            this._checkPathSynchronizedToList();

            if (newItem._owningPathSegList) {
                // SVG2 spec says to make a copy.
                newItem = newItem.clone();
            }
            this._checkValidIndex(index);
            this._list[index] = newItem;
            newItem._owningPathSegList = this;
            this._writeListToPath();
            return newItem;
        }

        window.SVGPathSegList.prototype.removeItem = function(index) {
            this._checkPathSynchronizedToList();

            this._checkValidIndex(index);
            var item = this._list[index];
            this._list.splice(index, 1);
            this._writeListToPath();
            return item;
        }

        window.SVGPathSegList.prototype.appendItem = function(newItem) {
            this._checkPathSynchronizedToList();

            if (newItem._owningPathSegList) {
                // SVG2 spec says to make a copy.
                newItem = newItem.clone();
            }
            this._list.push(newItem);
            newItem._owningPathSegList = this;
            // TODO: Optimize this to just append to the existing attribute.
            this._writeListToPath();
            return newItem;
        }

        window.SVGPathSegList._pathSegArrayAsString = function(pathSegArray) {
            var string = "";
            var first = true;
            pathSegArray.forEach(function(pathSeg) {
                if (first) {
                    first = false;
                    string += pathSeg._asPathString();
                } else {
                    string += " " + pathSeg._asPathString();
                }
            });
            return string;
        }

        // This closely follows SVGPathParser::parsePath from Source/core/svg/SVGPathParser.cpp.
        window.SVGPathSegList.prototype._parsePath = function(string) {
            if (!string || string.length == 0)
                return [];

            var owningPathSegList = this;

            var Builder = function() {
                this.pathSegList = [];
            }

            Builder.prototype.appendSegment = function(pathSeg) {
                this.pathSegList.push(pathSeg);
            }

            var Source = function(string) {
                this._string = string;
                this._currentIndex = 0;
                this._endIndex = this._string.length;
                this._previousCommand = window.SVGPathSeg.PATHSEG_UNKNOWN;

                this._skipOptionalSpaces();
            }

            Source.prototype._isCurrentSpace = function() {
                var character = this._string[this._currentIndex];
                return character <= " " && (character == " " || character == "\n" || character == "\t" || character == "\r" || character == "\f");
            }

            Source.prototype._skipOptionalSpaces = function() {
                while (this._currentIndex < this._endIndex && this._isCurrentSpace())
                    this._currentIndex++;
                return this._currentIndex < this._endIndex;
            }

            Source.prototype._skipOptionalSpacesOrDelimiter = function() {
                if (this._currentIndex < this._endIndex && !this._isCurrentSpace() && this._string.charAt(this._currentIndex) != ",")
                    return false;
                if (this._skipOptionalSpaces()) {
                    if (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) == ",") {
                        this._currentIndex++;
                        this._skipOptionalSpaces();
                    }
                }
                return this._currentIndex < this._endIndex;
            }

            Source.prototype.hasMoreData = function() {
                return this._currentIndex < this._endIndex;
            }

            Source.prototype.peekSegmentType = function() {
                var lookahead = this._string[this._currentIndex];
                return this._pathSegTypeFromChar(lookahead);
            }

            Source.prototype._pathSegTypeFromChar = function(lookahead) {
                switch (lookahead) {
                case "Z":
                case "z":
                    return window.SVGPathSeg.PATHSEG_CLOSEPATH;
                case "M":
                    return window.SVGPathSeg.PATHSEG_MOVETO_ABS;
                case "m":
                    return window.SVGPathSeg.PATHSEG_MOVETO_REL;
                case "L":
                    return window.SVGPathSeg.PATHSEG_LINETO_ABS;
                case "l":
                    return window.SVGPathSeg.PATHSEG_LINETO_REL;
                case "C":
                    return window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_ABS;
                case "c":
                    return window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_REL;
                case "Q":
                    return window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_ABS;
                case "q":
                    return window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_REL;
                case "A":
                    return window.SVGPathSeg.PATHSEG_ARC_ABS;
                case "a":
                    return window.SVGPathSeg.PATHSEG_ARC_REL;
                case "H":
                    return window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_ABS;
                case "h":
                    return window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_REL;
                case "V":
                    return window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_ABS;
                case "v":
                    return window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_REL;
                case "S":
                    return window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_ABS;
                case "s":
                    return window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_REL;
                case "T":
                    return window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_ABS;
                case "t":
                    return window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_REL;
                default:
                    return window.SVGPathSeg.PATHSEG_UNKNOWN;
                }
            }

            Source.prototype._nextCommandHelper = function(lookahead, previousCommand) {
                // Check for remaining coordinates in the current command.
                if ((lookahead == "+" || lookahead == "-" || lookahead == "." || (lookahead >= "0" && lookahead <= "9")) && previousCommand != window.SVGPathSeg.PATHSEG_CLOSEPATH) {
                    if (previousCommand == window.SVGPathSeg.PATHSEG_MOVETO_ABS)
                        return window.SVGPathSeg.PATHSEG_LINETO_ABS;
                    if (previousCommand == window.SVGPathSeg.PATHSEG_MOVETO_REL)
                        return window.SVGPathSeg.PATHSEG_LINETO_REL;
                    return previousCommand;
                }
                return window.SVGPathSeg.PATHSEG_UNKNOWN;
            }

            Source.prototype.initialCommandIsMoveTo = function() {
                // If the path is empty it is still valid, so return true.
                if (!this.hasMoreData())
                    return true;
                var command = this.peekSegmentType();
                // Path must start with moveTo.
                return command == window.SVGPathSeg.PATHSEG_MOVETO_ABS || command == window.SVGPathSeg.PATHSEG_MOVETO_REL;
            }

            // Parse a number from an SVG path. This very closely follows genericParseNumber(...) from Source/core/svg/SVGParserUtilities.cpp.
            // Spec: http://www.w3.org/TR/SVG11/single-page.html#paths-PathDataBNF
            Source.prototype._parseNumber = function() {
                var exponent = 0;
                var integer = 0;
                var frac = 1;
                var decimal = 0;
                var sign = 1;
                var expsign = 1;

                var startIndex = this._currentIndex;

                this._skipOptionalSpaces();

                // Read the sign.
                if (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) == "+")
                    this._currentIndex++;
                else if (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) == "-") {
                    this._currentIndex++;
                    sign = -1;
                }

                if (this._currentIndex == this._endIndex || ((this._string.charAt(this._currentIndex) < "0" || this._string.charAt(this._currentIndex) > "9") && this._string.charAt(this._currentIndex) != "."))
                    // The first character of a number must be one of [0-9+-.].
                    return undefined;

                // Read the integer part, build right-to-left.
                var startIntPartIndex = this._currentIndex;
                while (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) >= "0" && this._string.charAt(this._currentIndex) <= "9")
                    this._currentIndex++; // Advance to first non-digit.

                if (this._currentIndex != startIntPartIndex) {
                    var scanIntPartIndex = this._currentIndex - 1;
                    var multiplier = 1;
                    while (scanIntPartIndex >= startIntPartIndex) {
                        integer += multiplier * (this._string.charAt(scanIntPartIndex--) - "0");
                        multiplier *= 10;
                    }
                }

                // Read the decimals.
                if (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) == ".") {
                    this._currentIndex++;

                    // There must be a least one digit following the .
                    if (this._currentIndex >= this._endIndex || this._string.charAt(this._currentIndex) < "0" || this._string.charAt(this._currentIndex) > "9")
                        return undefined;
                    while (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) >= "0" && this._string.charAt(this._currentIndex) <= "9") {
                        frac *= 10;
                        decimal += (this._string.charAt(this._currentIndex) - "0") / frac;
                        this._currentIndex += 1;
                    }
                }

                // Read the exponent part.
                if (this._currentIndex != startIndex && this._currentIndex + 1 < this._endIndex && (this._string.charAt(this._currentIndex) == "e" || this._string.charAt(this._currentIndex) == "E") && (this._string.charAt(this._currentIndex + 1) != "x" && this._string.charAt(this._currentIndex + 1) != "m")) {
                    this._currentIndex++;

                    // Read the sign of the exponent.
                    if (this._string.charAt(this._currentIndex) == "+") {
                        this._currentIndex++;
                    } else if (this._string.charAt(this._currentIndex) == "-") {
                        this._currentIndex++;
                        expsign = -1;
                    }

                    // There must be an exponent.
                    if (this._currentIndex >= this._endIndex || this._string.charAt(this._currentIndex) < "0" || this._string.charAt(this._currentIndex) > "9")
                        return undefined;

                    while (this._currentIndex < this._endIndex && this._string.charAt(this._currentIndex) >= "0" && this._string.charAt(this._currentIndex) <= "9") {
                        exponent *= 10;
                        exponent += (this._string.charAt(this._currentIndex) - "0");
                        this._currentIndex++;
                    }
                }

                var number = integer + decimal;
                number *= sign;

                if (exponent)
                    number *= Math.pow(10, expsign * exponent);

                if (startIndex == this._currentIndex)
                    return undefined;

                this._skipOptionalSpacesOrDelimiter();

                return number;
            }

            Source.prototype._parseArcFlag = function() {
                if (this._currentIndex >= this._endIndex)
                    return undefined;
                var flag = false;
                var flagChar = this._string.charAt(this._currentIndex++);
                if (flagChar == "0")
                    flag = false;
                else if (flagChar == "1")
                    flag = true;
                else
                    return undefined;

                this._skipOptionalSpacesOrDelimiter();
                return flag;
            }

            Source.prototype.parseSegment = function() {
                var lookahead = this._string[this._currentIndex];
                var command = this._pathSegTypeFromChar(lookahead);
                if (command == window.SVGPathSeg.PATHSEG_UNKNOWN) {
                    // Possibly an implicit command. Not allowed if this is the first command.
                    if (this._previousCommand == window.SVGPathSeg.PATHSEG_UNKNOWN)
                        return null;
                    command = this._nextCommandHelper(lookahead, this._previousCommand);
                    if (command == window.SVGPathSeg.PATHSEG_UNKNOWN)
                        return null;
                } else {
                    this._currentIndex++;
                }

                this._previousCommand = command;

                switch (command) {
                case window.SVGPathSeg.PATHSEG_MOVETO_REL:
                    return new window.SVGPathSegMovetoRel(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_MOVETO_ABS:
                    return new window.SVGPathSegMovetoAbs(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_REL:
                    return new window.SVGPathSegLinetoRel(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_ABS:
                    return new window.SVGPathSegLinetoAbs(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_REL:
                    return new window.SVGPathSegLinetoHorizontalRel(owningPathSegList, this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_HORIZONTAL_ABS:
                    return new window.SVGPathSegLinetoHorizontalAbs(owningPathSegList, this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_REL:
                    return new window.SVGPathSegLinetoVerticalRel(owningPathSegList, this._parseNumber());
                case window.SVGPathSeg.PATHSEG_LINETO_VERTICAL_ABS:
                    return new window.SVGPathSegLinetoVerticalAbs(owningPathSegList, this._parseNumber());
                case window.SVGPathSeg.PATHSEG_CLOSEPATH:
                    this._skipOptionalSpaces();
                    return new window.SVGPathSegClosePath(owningPathSegList);
                case window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_REL:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), x2: this._parseNumber(), y2: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoCubicRel(owningPathSegList, points.x, points.y, points.x1, points.y1, points.x2, points.y2);
                case window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_ABS:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), x2: this._parseNumber(), y2: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoCubicAbs(owningPathSegList, points.x, points.y, points.x1, points.y1, points.x2, points.y2);
                case window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_REL:
                    var points = {x2: this._parseNumber(), y2: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoCubicSmoothRel(owningPathSegList, points.x, points.y, points.x2, points.y2);
                case window.SVGPathSeg.PATHSEG_CURVETO_CUBIC_SMOOTH_ABS:
                    var points = {x2: this._parseNumber(), y2: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoCubicSmoothAbs(owningPathSegList, points.x, points.y, points.x2, points.y2);
                case window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_REL:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoQuadraticRel(owningPathSegList, points.x, points.y, points.x1, points.y1);
                case window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_ABS:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegCurvetoQuadraticAbs(owningPathSegList, points.x, points.y, points.x1, points.y1);
                case window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_REL:
                    return new window.SVGPathSegCurvetoQuadraticSmoothRel(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_CURVETO_QUADRATIC_SMOOTH_ABS:
                    return new window.SVGPathSegCurvetoQuadraticSmoothAbs(owningPathSegList, this._parseNumber(), this._parseNumber());
                case window.SVGPathSeg.PATHSEG_ARC_REL:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), arcAngle: this._parseNumber(), arcLarge: this._parseArcFlag(), arcSweep: this._parseArcFlag(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegArcRel(owningPathSegList, points.x, points.y, points.x1, points.y1, points.arcAngle, points.arcLarge, points.arcSweep);
                case window.SVGPathSeg.PATHSEG_ARC_ABS:
                    var points = {x1: this._parseNumber(), y1: this._parseNumber(), arcAngle: this._parseNumber(), arcLarge: this._parseArcFlag(), arcSweep: this._parseArcFlag(), x: this._parseNumber(), y: this._parseNumber()};
                    return new window.SVGPathSegArcAbs(owningPathSegList, points.x, points.y, points.x1, points.y1, points.arcAngle, points.arcLarge, points.arcSweep);
                default:
                    throw "Unknown path seg type."
                }
            }

            var builder = new Builder();
            var source = new Source(string);

            if (!source.initialCommandIsMoveTo())
                return [];
            while (source.hasMoreData()) {
                var pathSeg = source.parseSegment();
                if (!pathSeg)
                    return [];
                builder.appendSegment(pathSeg);
            }

            return builder.pathSegList;
        }
    }
}());

/dev/horse/0001/README.md

# SVGアニメーション
SVGによる馬のアニメーションです。
[エドワード・マイブリッジ](http://upload.wikimedia.org/wikipedia/commons/7/73/The_Horse_in_Motion.jpg)の「Horse in motion」をInkscapeでトレースし、各馬をセル化してアニメーションしています。

/dev/horse/0001/thumbnail.png

2/28追記:上記リンク先はIE11/Firefoxでは正常に表示されない。

ようやくgeometory変換に着手できそうだ。
